Smart LCD Display Heating Thermostat

Description:
The programming heating thermostat is a multi-functional and richly featured programmable touch screen thermostat. The thermostat adopts the latest single-chip computer control technology, and its application is the electric heating equipment and water heating system of electric heating or actuator control. According to the preset temperature, the thermostat will automatically start and stop the controlled object (valve, floor heating, the heating wall, electric heater etc.).

Features and functions:
– Circular LCD display with white backlight
– Time modes: 3
– Free to choose manual mode or full automatic mode for different purposes
– High reliability, energy-saving and powerful anti-jamming
– Unique circular shape and humanized design
– Flame retardant and safe and easy-cleaning
– Stylish appearance and its mirror screen would be very easy to clean
– Power outage will not affect the period setting value
– Keypad locking function is designed to prevent the children from misusing

Technical parameters:
– Power supply: AC 85-250V 50/60 Hz (240V optional)
– Maximum switch power: 16A
– Inside sensor: NTC B: 3380 10k 25 Deg.C
– Internal sensor measurement range: 0 – 40 Deg.C
– Setting range: 5 – 35 Deg.C (factory settings: 22 Deg.C)
– Display resolution: 0.1 Deg.C
– Setting unit: 0.5 Deg.C/step
– Unite dimension: 86 x 86 x 33mm
– Size of display: 50mm (diameter)
– Unite weight: 150 – 155g (with plate)
– Backlight color: white

Caution:
Electrical hazard can cause electrical shock or equipment damage. Disconnect power before installation.
